15 seats Pure Electric Bus RHD

SYSTEM

PART NAME

DESCRIPTION

Basic specification

Dimension(mm)

5030 ×1700 ×2260

Wheelbase(mm)

2590

Front/Rear Overhang(mm)

1300/ 1140

Approach/Departure

18° / 13°

Max speed(km/h)

100

Seat capacity

15 seats

Electric system

Motor type

Permanent magnet synchronous motor

Rated/Peak torque (N.m)

130/270

Rated/Peak power (kW)

50/80

Battery type

Lithium iron phosphate

Battery capacity (kWh)

50.23kwh
*Range 200km-240km under NEDC

Interface

Chinese standard charging interface

Charger input voltage

220V / 6.6KW

CHASSIS

steering system

Power steering, RHD

Front suspension

independent suspension

Rear suspension

Leaf spring

Brake system

Front disc/Rear drum

Electric braking system

ABS+EBD

Tire

195/70R15 Tire+ steel rims

BODY

Inner trim

Standard luxury type

Dashboard

standard luxury dashboard

Doors

4 doors

Middle Door Type

Left sliding door

Emergency Hammer

Equipped

Side Window

sliding window

window regulator

Electronic control

Rearview mirror

Electronic control

Fire Extinguisher

Equipped

ELECTRICAL EQUIPMENT

Air Conditioner

Front and rear air conditioner

Heater

Equipped

Reversing Monitor

Equipped

Audio visual system

Andriod LCD screen, with radio, GPS, bluetooth, USB, SD card
